PCI-E SATA&SAS kort
(0 recensioner)

LSI MegaRAID SAS 9361-8i

7 995 kr
  • Lagerstatus: Beställningsvara
  • Frakt från: 0 kr
  • Artikelnr.
  • 5010856389
  • Tillv. art. nr.
  • LSI00417

Snabbfakta

Anslutning
PCIe 3.0 x8
Gränssnitt
SATA 6Gb/s / SAS 12Gb/s

Nyckelfunktioner

  • Connect up to 128 SATA or SAS drives with eight internal 12Gb/s SATA and SAS ports
  • Fit into rack-mounted servers with low-profile form factor and side-mounted SAS connectors
  • Support critical, high-bandwidth applications with PCIe 3.0 connectivity
  • Balance protection and performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, and 60
  • Add more protection and peace of mind with optional CacheVault flash cache protection.

Produktinformation

Datacenter, cloud and high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection and performance today's applications and end users demand. The MegaRAID SAS 9361-8i 12Gb/s SAS and SATA RAID controller card addresses these needs by delivering proven performance and RAID data protection for a range of server storage applications.

Specifikationer

Allmänt
Tillverkare LSI
Förpackad kvantitet 1
Modell SAS 9361-8i
Produktlinje LSI MegaRAID
Produkttyp Kontrollerkort (RAID)
Enhetstyp Storage controller (RAID) - plug-in card - low profile
Kontrollerkort
Anslutning PCIe 3.0 x8
Gränssnitt SATA 6Gb/s / SAS 12Gb/s
Formfaktor Instickskort
Max antal enheter 128
RAID-stöd RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Enheter som stöds Hårddisk, Disk array (RAID), Halvledarenhet
Storage Controller
Data Transfer Rate 12 GBps
Hårddisk och Lagring
Microsoft-certifiering Compatible with Windows 7
Systemkrav
Operativsystemsstöd SunSoft Solaris, Novell NetWare , Linux , Microsoft Windows Vista, FreeBSD, Microsoft Windows 2003, Microsoft Windows Server 2008, Microsoft Windows Server 2012, VMware ESX, Microsoft Windows XP, Microsoft Windows 7 / Windows 8
Medföljande programvara
Inkluderad programvara MegaRAID Storage Manager, MegaRAID Fast Path
Standarder som följs
Kompatibel standard FCC Class B certified, FCC Class A certified, UL, VCCI, C-Tick, BSMI, EN 60950, EN 61000-3-2, EN55022, ICES-003, RRL, UL 1950, EN 61000-3-3, EN55024, MIC, AS/NZS 3548, CSA C22.2, EMC Class B
Miljö Parametrar
Högsta temperatur vid drift 55 °C
Expansion/Anslutning
Anslutningar 2 x SATA 6Gb/s / SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8643) ( internal )
Mått och vikt
Yttermått bredd 6.44 cm
Yttermått djup 16.8 cm
Diverse
MTBF 1,343,187 hour(s)
Miscellaneous
Compatible with Windows 7 "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7.
Service och support
Service & support 3 års garanti
Service & Support detaljer 3 år
Service & Support 3 år
